| Items | Characteristics |
| Category Temperature Range | -40 ~ 105°C |
| Rated Voltage Range | 6.3 ~ 100Vdc |
| Capacitance Tolerance | ± 20% (M) (at 20’C ,120Hz) |
| Leakage Current | 1≤0.01CV or 3 uA whichever is greater Where 1: Max. leakage current(uA). C: Nominal capacitance(uF), V: Rated voltage(V) (at 20C after 2 minutes) |
| Dissipation Factor (tan 6) | Rated Voltage (Vdc) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 |
| tan δ (max) | 0.22 | 0.19 | 0.16 | 0.14 | 0.12 | 0.1 | 0.09 | 0.08 |
| When nominal capacitance exceeds 1,000uF, add 0.02 to the value above for each 1,000uF increase |
| Low Temperature Characteristics (Max, Impedance Ratio) | Rated Voltage (Vdc) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 |
| Z (-25 °C) /Z (+20°C) | 4 | 3 | 2 |
| Z (-40 °C) /Z (+20 °C) | 8 | 6 | 4 | 3 |
| Endurance | The following specification shall be satisfied when the capacitors are restored to 20°C after subjected to DC voltage with the rated ripple current is applied for the specified of time 105°C |
| | Case dia | life time(hours) |
| Capacitancechange | ≤+20% of the initial value(6.3V,10V:≤+30%) | | 6.3-10V | 16-100V |
| D.F.(tan δ) | ≤200% of the initial specified value | ΦD≤6.3 | 4,000 | 5,000 |
| Leakage current | ≤the initial specified value | ΦD=8&10 | 6,000 | 7,000 |
| | | | | | | | ΦD≥12.5 | 8,000 | 10,000 |
| Shelf life | The following specification shall be satisfied when the capacitors are restored to 20°C after exposing them for 1000 hours at 105°C without voltage applied. |
| Capacitancechange | ≤+20% of the initial value(6.3V,10V:≤+30%) | |
| D.F.(tan δ) | ≤200% of the initial specified value |
| Leakage current | ≤200% initial specified value |
